What are the instructions for using a bag filter?

There are also many things to pay attention to before operating a bag filter, so as to avoid unnecessary troubles during or after installation, which may also affect the service life of the bag filter. So what should we do?

1. Before starting the dust collector in each shift, check the oil level of the centrifugal fan unloader, the oil level of the fan bearing box, and check whether the foundation and fastening bolts are loose. Check if the pipeline air valve is in the set switch position. Check if the knob position of the pulse controller is appropriate.

2. Restart the shredder.

3. Start the dust collector before starting the crusher.

4. Turn on the pulse controller and start working the dust collector.

5. During the operation of the dust collector, start the unloader 5-10 minutes before stopping each shift to discharge the dust. A soft cloth tube should be connected to the ash discharge pipe near the belt to allow dust to slowly flow on the belt and prevent secondary dust.

6. The pointer of the electric valve is open at 900 and closed at 00.

7. The manual valve rotates clockwise to close and counterclockwise to open.

8. The left knob of the pulse controller controls the opening degree of the blowing solenoid valve, with left rotation indicating small and right rotation indicating large. The right knob controls the pulse blowback time, with left rotation for short and right rotation for long. Generally, it is adjusted to about one minute (check the meter to adjust the time), and the positions of both knobs are usually set to around 450 for right rotation.

9. The use, maintenance, and cleaning of the dust collector are the responsibility of the crusher driver. And keep a record of the operation of the dust collector.
